pfSense Initial Setup: Complete Installation Guide (2026)

pfSense CE and pfSense Plus are FreeBSD-based firewall and routing platforms developed by Netgate. This guide walks you through a fresh install from USB to a working WAN+LAN configuration.

Hardware: What you need

Any x86-64 system with at least two NICs works. Common homelab choices:

• Protectli FW4C — Intel J3160, 4×GbE, fanless, ~$250 used — community favorite for pfSense CE
• Netgate 1100 — ARM-based, ~$189, ships with pfSense Plus pre-installed
• Netgate 2100 — ARM-based (Marvell OCTEON TX2), official hardware, ~$349, pfSense Plus
• Topton/Cwwk N5105 mini-PC — 4×GbE or 2.5GbE, ~$200, runs pfSense CE well

For a basic WAN+LAN setup any two-NIC x86-64 box is sufficient. Note: pfSense Plus is only officially supported on Netgate hardware or as a paid cloud image; pfSense CE runs on any x86-64.

Download the installer

pfSense CE (free, community edition):

1. Go to the pfSense download page and select the AMD64 DVD ISO (installer image).
2. Write to USB: dd if=pfSense-CE-*.iso of=/dev/sdX bs=4M status=progress (Linux/macOS).

pfSense Plus (Netgate hardware):

• Comes pre-installed on Netgate appliances. Updates available through the web UI.

Boot and install

1. Boot from USB. The installer launches automatically.
2. Accept the copyright notice → select Install pfSense.
3. Choose Auto (ZFS) for disk layout on modern hardware (recommended), or Auto (UFS) for compatibility.
4. Select your disk → confirm destruction → let install complete.
5. Reboot, remove USB.

Interface assignment

At the console menu, select 1 — Assign Interfaces:

Should VLANs be set up now? → n
Enter the WAN interface name or 'a' for auto-detection: igb0
Enter the LAN interface name: igb1
Do you want to proceed? → y

pfSense will assign interfaces and reboot.

First-boot web UI access

From a LAN-connected device, browse to https://192.168.1.1. Default credentials: admin / pfsense.

The Setup Wizard launches automatically:

• Set hostname and domain (e.g., firewall.home.arpa)
• Configure DNS (1.1.1.1 + 9.9.9.9 or your preferred upstream)
• Set timezone
• Configure WAN (DHCP for most ISPs, PPPoE if required)
• Confirm LAN IP (default 192.168.1.1/24)
• Change the admin password — required step at the end of the wizard

Immediate hardening steps

Before doing anything else:

1. Disable HTTP redirect — System → Advanced → Admin Access → uncheck “HTTP Redirect”
2. Lock SSH to key-auth — System → Advanced → Admin Access → enable SSH, set auth to key only
3. Enable auto-update notifications — System → Update → Branch: Latest Stable
4. Set secure DNS — System → General Setup → DNS servers: 1.1.1.1 (Enable DNS Resolver)

Next steps

• VLAN configuration on pfSense — segment IoT, guest, and trusted traffic
• pfBlockerNG setup — DNS-based ad and tracker blocking
• Snort IDS/IPS on pfSense — inline intrusion detection
